PRODUCT DESCRIPTION
The Harvia Legend 240 BimSchV2 Black Wood Burning Heater brings real wood-fired heat into a medium-sized sauna. It uses natural wood fuel and gives the sauna a warm, traditional feel.
The black steel frame holds a large amount of sauna stones. As the stones heat up, they create soft steam and steady warmth. Also, the large stone space helps keep the sauna comfortable, even if the fire slows down during use.
The fire chamber uses a modern grate system. This system guides part of the air to the upper fire chamber. As a result, the heater burns wood more cleanly and uses the fire more efficiently.
The cast-iron glass door lets you see the warm glow of the fire. Because of this, the heater adds a calm and relaxing mood to the sauna room.
In addition, the adjustable legs make placement easier. They help you set the heater in the right position and adjust the smoke outlet height when needed.
FEATURES
Authentic Wood-Fired Sauna Heat
This heater uses natural wood fuel. Therefore, it gives your sauna a classic heat and steam experience.
Large Stone Space
The frame holds many sauna stones. As a result, the heater creates soft steam and steady heat for longer sauna sessions.
Cleaner and More Efficient Burning
The modern grate system guides air inside the fire chamber. Because of this, the heater burns wood more cleanly and efficiently.
Cast-Iron Glass Door
The glass door shows the fire inside the heater. Also, it adds a warm glow to the sauna room.
Adjustable Legs
The adjustable legs help during installation. They also make it easier to set the smoke outlet height.
Instructions for Using Your Harvia Sauna Heater
Piling of the Sauna Stones
Properly arranging sauna heater stones is essential for both safety and warranty compliance. Follow these guidelines:
Use suitable sauna stone materials such as peridotite, olivine diabase, olivine, and vulcanite.
Only use cleavage surfaces and/or rounded stones on your sauna heater.
If heating elements come into contact with the stones, use rounded stones only in the outer layers of the stone space.
Decorative stones should be placed loosely to allow air circulation and should not touch heating elements.
Stones should be 5–15 cm in diameter.
Wash off dust from the stones before piling them into the heater.
When placing the stones, don’t drop stones into the heater.
Don’t wedge stones between heating elements.
Space stones to ensure proper air circulation.
Pile stones to support each other rather than placing the weight on heating elements.
Avoid forming a high pile of stones on top of the heater.
Don’t place any objects or devices inside or near the heater that could alter airflow.
Heater Maintenance
Sauna stones can disintegrate due to temperature fluctuations. Rearrange stones at least annually, or more often with frequent sauna use.
Remove any disintegrated stones from the heater’s bottom and replace them with new ones to maintain optimal heating and prevent overheating.
Heating Your Sauna with Harvia Sauna Heater
When using the heater for the first time, both the heater and stones may emit odors. Efficiently ventilate the sauna room to remove these odors. If the heater’s output matches the sauna room’s size, it will take about an hour for a properly insulated sauna to reach the desired bathing temperature. The sauna stones typically reach this temperature simultaneously with the sauna room.
SPECIFICATIONS
| Specification | Details |
|---|---|
| Model | WKLE20M10 |
| Product Name | Harvia Legend 240 BimSchV2 Black Wood Burning Heater |
| Product Type | Wood burning sauna heater |
| Power Output | 21 kW |
| Recommended Sauna Room Size | 10–24 m³ |
| Colour | Black |
| Main Material | Steel |
| Stone Amount | 200 kg |
| Stone Size | Ø10–15 cm |
| Chimney Connection Locations | Back and top |
| Chimney Connection Diameter | 115 mm |
| Minimum Flue Pipe Internal Diameter | 110 mm |
| Chimney Temperature Class | T600 |
| Certifications | CE, BImSchV2, EAC |
| BImSchV2 | German clean air standard |
| Measurements | |
|---|---|
| Height | 830 mm |
| Width | 600 mm |
| Depth | 600 mm |
| Adjustable Legs | 0–30 mm |
| Net Weight | 75 kg |
| Safety and Installation Dimensions | |
|---|---|
| Safety Distance Front | 630 mm |
| Safety Distance Right Side – Combustible Materials | 200 mm |
| Safety Distance Left Side – Combustible Materials | 200 mm |
| Safety Distance Behind – Combustible Materials | 250 mm |
| Safety Distance to Ceiling | 1200 mm |
| Room Minimum Height | 2100 mm |
| Logistic Data | |
|---|---|
| EAN | 6417659043274 |
| Package Width | 620 mm |
| Package Height | 870 mm |
| Package Depth | 620 mm |
| Gross Weight | 85.5 kg |
WARRANTY
Residential Use: 3 years total (24 months + 12-month extension when registered and used with Harvia sauna stones).
WHAT’S INCLUDED
Harvia Legend 240 BimSchV2 black wood burning heater
Installation and operating instructions
Note: Sauna stones, flue kit, protective sheath, smoke pipe cover, and water heater accessories are sold separately unless included in a specific package or bundle.
Experience Traditional Sauna Heat with Harvia Legend
The Harvia Legend 240 BimSchV2 suits sauna users who want real wood-fired heat, soft steam, and a warm fire glow. In addition, the large stone space helps keep the sauna heat steady.
For a more complete setup, you can add matching Harvia accessories such as protective bedding, protective sheaths, smoke pipe guards, flue kits, and sauna stones.
