Traditional Wood-Fired Sauna Heat for Medium-Sized Saunas
Experience a strong and authentic sauna atmosphere with the Harvia Pro 20 BimSchV2 Black Wood Burning Heater. Designed for medium-sized saunas, this wood-fired heater features a large stone compartment for pleasant, hearty steam and a cast-iron-framed glass door that adds warmth and ambience to your sauna space.
Why Choose the Harvia Pro 20?
Key Features
Thoughtful Design Details
Versatile Applications
2 in stock
Any questions? We’re here to help. Send us a message or chat with one of our sauna specialist.
Did you know? We offer one of Australia’s largest ranges of premium sauna products & materials — heaters, hot tubs, accessories, and more
The Harvia Pro 20 BimSchV2 Black Wood Burning Heater brings classic wood-fired heat to medium-sized sauna rooms. It gives the sauna a warm and traditional feel.
The large stone space helps create steady heat and soft steam. Also, the fire behind the glass door adds a calm glow to the sauna room.
The heater uses a strong steel body and a sturdy fire chamber cover. As a result, it suits regular sauna use and gives reliable performance.
In addition, the adjustable feet make installation easier. They help you set the heater height and align the smoke outlet when needed.
You can also add a pipe model water heater. Therefore, this model works well for sauna owners who want a simple and practical wood-fired setup.
This heater uses natural wood fuel. Therefore, it gives your sauna a real traditional heat experience.
The heater holds up to 40 kg of sauna stones. As a result, it creates soft steam and steady warmth.
The glass door lets you see the fire inside. Also, it adds a relaxing glow to the sauna room.
The steel body and 10 mm fire chamber cover add strength. Because of this, the heater suits regular sauna use.
You can add a pipe model water heater. As a result, the heater can support a more complete sauna setup.
Properly arranging sauna heater stones is essential for both safety and warranty compliance. Follow these guidelines:
Use suitable sauna stone materials such as peridotite, olivine diabase, olivine, and vulcanite.
Only use cleavage surfaces and/or rounded stones on your sauna heater.
If heating elements come into contact with the stones, use rounded stones only in the outer layers of the stone space.
Decorative stones should be placed loosely to allow air circulation and should not touch heating elements.
Stones should be 5–15 cm in diameter.
Wash off dust from the stones before piling them into the heater.
When placing the stones, don’t drop stones into the heater.
Don’t wedge stones between heating elements.
Space stones to ensure proper air circulation.
Pile stones to support each other rather than placing the weight on heating elements.
Avoid forming a high pile of stones on top of the heater.
Don’t place any objects or devices inside or near the heater that could alter airflow.
Sauna stones can disintegrate due to temperature fluctuations. Rearrange stones at least annually, or more often with frequent sauna use.
Remove any disintegrated stones from the heater’s bottom and replace them with new ones to maintain optimal heating and prevent overheating.
When using the heater for the first time, both the heater and stones may emit odors. Efficiently ventilate the sauna room to remove these odors. If the heater’s output matches the sauna room’s size, it will take about an hour for a properly insulated sauna to reach the desired bathing temperature. The sauna stones typically reach this temperature simultaneously with the sauna room.
| Specification | Details |
|---|---|
| Model | WKPR20M10 |
| Product Name | Harvia Pro 20 BimSchV2 Black Wood Burning Heater |
| Product Type | Wood burning sauna heater |
| Power Output | 24.1 kW |
| Recommended Sauna Room Size | 8–20 m³ |
| Colour | Black |
| Main Material | Steel |
| Stone Amount | 40 kg |
| Stone Size | Ø10–15 cm |
| Chimney Connection Locations | Back and top |
| Chimney Connection Diameter | 115 mm |
| Certifications | CE, BImSchV2, EAC |
| BImSchV2 | German clean air standard |
| Measurements | |
|---|---|
| Height | 740 mm |
| Width | 585 mm |
| Depth | 510 mm |
| Net Weight | 58 kg |
| Safety and Installation Dimensions | |
|---|---|
| Safety Distance Front – Non-Combustible Materials | 300 mm |
| Safety Distance Front – Combustible Materials | 300 mm |
| Safety Distance Right Side – Combustible Materials | 300 mm |
| Safety Distance Right Side – Non-Combustible Materials | 100 mm |
| Safety Distance Left Side – Combustible Materials | 300 mm |
| Safety Distance Left Side – Non-Combustible Materials | 100 mm |
| Safety Distance Behind – Combustible Materials | 300 mm |
| Safety Distance Behind – Non-Combustible Materials | 100 mm |
| Safety Distance to Ceiling | 1300 mm |
| Room Minimum Height | 2090 mm |
| Logistic Data | |
|---|---|
| EAN | 6417659043298 |
| Electrical Number (STK) | – |
| Customs Tariff Number | 73218900 |
| ETIM Number | EC001884 |
| UNSPSC Number | – |
| Packaging Material | Cardboard |
| Package Width | 515 mm |
| Package Height | 785 mm |
| Package Depth | 460 mm |
| Gross Weight | 62.4 kg |
Residential Use: 3 years total (24 months + 12-month extension when registered and used with Harvia sauna stones).
Harvia Pro 20 BimSchV2 black wood burning heater
Fastening kit
Installation and operating instructions
Note: Sauna stones, flue kit, protective sheath, and water heater accessories are sold separately unless included in a specific package or bundle.
The Harvia Pro 20 BimSchV2 suits sauna users who want real wood-fired heat, soft steam, and a warm fire glow. In addition, the strong steel build supports regular sauna use.
For a more complete setup, you can add Harvia accessories such as sauna stones, flue kits, protective sheaths, and water heater accessories.
